Air Cooled Scroll Chiller

Your Premier Air Cooled Scroll Chiller Manufacturer and Supplier

Fidem Chillers, a trusted brand of Aquatech Plus Pvt. Ltd., is India’s leading manufacturer and supplier of high-performance Air Cooled Scroll Chillers. With 15+ years of engineering excellence, Fidem provides energy-efficient, reliable, and customizable solutions tailored for industrial and commercial cooling applications.

Key Features of Fidem Air Cooled Scroll Chillers

  • Capacity Range: 1 TR to 200 TR
  • Energy Efficient: High EER scroll compressors
  • Low Noise Design: Quiet external rotor fans
  • Modular Options: Expandable in multi-circuit formats
  • Flexible Refrigerants: R22 / R407C / R134a / R404A / R410A
  • Versatile Heat Exchangers: SS coil, plate, or shell & tube
  • Smart Controls: Optional PLC/SCADA/BMS compatibility
  • Built-in Pump Options: Customizable pumping head and flow
  • Rating Conditions
  • Chilled Water Inlet/Outlet Temperature: 12℃ / 7℃
  • Ambient Air Inlet/Outlet Temperature: 33℃ / 38℃
  • Note: We reserve the right to modify the specifications without prior notice.
  • Air Cooled Scroll Chiller – An Ultimate FAQ Guide by Fidem Chillers

Applications of Air Cooled Scroll Chiller

Air Cooled Scroll Chillers are widely used in both commercial and industrial sectors due to their energy efficiency, compact design, and easy installation.

  • Industrial Applications:
  • Plastic Moulding & Extrusion Machines
  • Pharmaceutical Manufacturing (capsule, tablet cooling)
  • Chemical & Process Cooling
  • Dairy, Beverage, and Food Processing Units
  • Anodizing and Electroplating Plants
  • Laser Machines and Welding Equipment Cooling
  • Blow Moulding / Injection Moulding Cooling
  • Commercial Applications:
  • HVAC for Hotels, Hospitals, Office Buildings
  • Data Centers
  • Server Room Cooling
  • Cold Room Pre-Cooling
  • Retail Malls and Multiplexes
1. Why Fidem Chillers is Your Reliable Air Cooled Scroll Chiller Manufacturer in India?
  • Over 15 years of experience
  • ISO, CE, RoHS certified
  • Manufacturing facility with 100+ skilled professionals
  • Custom-built solutions for industrial and process cooling
  • 24/7 technical support and spare part availability

  • Compressor: Hermetically sealed scroll or piston type

    • Condenser: Finned copper tube with aluminum fins + axial fans
    • Evaporator: Plate, SS coil-in-tank, or shell & tube
    • Expansion Device: Thermostatic valve / Capillary
    • Refrigerant: R22, R407C, R134a, R410A, R404A
    • Control Panel: Digital / PLC / SCADA
    • Pump (Optional): Integrated chilled water pump
    • Frame: Powder coated GI / SS304
  • Compressor Sound Level: 65–75 dB(A) at 1 meter
  • Fan Sound Level: 60–70 dB(A)
  • Power Consumption: Varies from 1.1 kW (1 TR) to 180 kW (200 TR)
  • Low Noise Option: Acoustic insulation and inverter fan (on request)
  • Always use flexible hoses at connections to absorb vibration.
  • Follow proper inlet/outlet orientation as per drawing.
  • Install Y-strainer before inlet.
  • Ensure no backflow or air pockets in the system.
  • Provide drain point at the lowest point and vent point at the highest.
  • Use insulated pipelines to prevent sweating and thermal loss.
  • Compressor overload protection
  • High/low pressure switch
  • Flow switch (no flow protection)
  • Over/under voltage protection
  • Phase sequence and phase failure relay
  • Anti-freezing sensor
  • Exhaust temperature sensor
  • Low refrigerant level protection
  • Emergency stop

  • Issue Possible Cause Solution

    Chiller not starting Phase error / Low voltage Check wiring and voltage

    Low cooling Clogged condenser / low gas Clean condenser / top-up refrigerant

    High pressure trip Fan not running / high ambient Inspect fan motor improve ventilation

    Water flow alarm  Air lock / pump issue Bleed line, check pump impeller

    Ice formation Low water flow / setpoint too low Increase water flow / adjust setpoint

Working Principle of Air Cooled Scroll Chiller

An Air Cooled Scroll Chiller works by absorbing heat from a process or space and releasing it into the air using fans and a refrigerant cycle.

  • Compresses low-pressure refrigerant vapor into high-pressure, high-temperature gas.
  • Scroll compressors operate quietly and with fewer moving parts.
  • Condenser (Air Cooled Finned Coil):
  • Ambient air blown over the coil by fans cools the refrigerant.
  • The refrigerant gas condenses into high-pressure liquid.
  • Expansion Valve (TXV or Capillary):
  • Reduces the pressure of liquid refrigerant.
  • Converts it into a low-pressure, low-temperature mixture.
  • Evaporator (SS Coil/Shell & Tube/PHE):
  • The refrigerant evaporates by absorbing heat from process water.
  • The water is cooled down to the desired temperature.
  • Chilled Water Circuit:
  • Chilled water is pumped from the evaporator to the application (mould, tank, coil).
  • After absorbing heat, it returns to the chiller for recirculation.

Key Components Overview:

  • Component Function
  • Scroll Compressor Compresses refrigerant vapor
  • Air Cooled Condenser Removes heat from refrigerant
  • Expansion Valve Controls refrigerant flow and pressure
  • Evaporator Transfers heat from water to refrigerant
  • Fan (Blower) Pulls ambient air over condenser
  • Pump (Optional) Circulates chilled water to user point
  • Controller Regulates temperature and system safety
💬
